Angle Apparatus

  • Angle Apparatus
  • Angle Apparatus
  • Angle Apparatus
Product Parameters
Description: Angle Apparatus
● Material: Cast Steel (Q355B) (The actual supply shall prevail)
● Surface: Phosphorylation black / Nitriding
● Continuously adjustable from 0° to 225° with precision scaling
● Holding force up to 1350 Nm torque with system 28
● Can be combined with other system components
● Horizontal and vertical application possible
● With precision scaling

Hole system

Specifications

Products Code

Surface

Weightkg

D28

475x100x100

SWK28-70001-B1

Blackening

49.3

475x100x100

SWK28-70001-B2

Nitriding

49.3

D22

475x100x100

SWK22-70001-B1

Blackening

32

475x100x100

SWK22-70001-B2

Nitriding

32

D16

250x50x50

SWK16-70001-B1

Blackening

8.3

250x50x50

SWK16-70001-B2

Nitriding

8.3

Fitting accessories











Bolts Countersunk Rapid Bolts  Countersunk Bolts Bolts with handle Brush   Ground Connector  Assembly lever


Related Locating Angles Products

Corner Module
Corner Module
Locating  Angle (system D16)
Locating Angle (system D16)
Locating  Angle (system D22)
Locating Angle (system D22)
Locating Angle (system D28)
Locating Angle (system D28)
